Portable Energy Storage

Product Model

P5 Pro

P10

P20  ,Pro

Output power

600W

1200W

 2200w

Battery

High-rate ternary battery cell

22.2V 499.5Wh

LFP 321401008Wh

High-rate ternary battery cell

43.2V 2203.2Wh

Charging specifications

Fast Charging:

China Standard: 200V-240V/50Hz

US/Japan Standard: 100V-120V/60Hz

EU/AU/UK Standard: 220V-240V/50Hz

Rated Input Power: 430W

Adapter: 200W/20V

Fast Charging:

China Standard: 200V-240V/50Hz

US/Japan Standard: 100V-120V/60Hz

EU/AU/UK Standard: 220V-240V/50Hz

Rated Input Power: 1800W

Solar Panel: MPPT

100W, 18V~24V, 5.6A

Solar Panel: MPPT

200W, 18-22V DC, 10A Max

Supports 18V and 36V solar panels, using two XT60 ports.

Maximum power support: 400W and 800W, with static MPPT efficiency >,99%.

Discharge specifications

USB output

USB-A

Dual outputs: Max 36W 5V/3A 9V/3A

12V/3A supports Apple 2.4A, QC2.0/3.0,

FCP, AFC, DCP, SCP

USB-A1:QC3.0/5V2.4A 9V2A
12V1.5A/BC1.2 AFC FCP
USB-A2:5V2.4A

Quad Output: 24W 5V/3A, 9V/2.5A, 12V/2A

Supports Apple 2.4A, PPS/PD3.0/PD2.0, QC4+/

QC4/QC3.0/QC2.0, AFC, FCP, Low-Voltage SCP/

High-Voltage SCP, PE2.0/PE1.1, SFCP Fast Charging Protocol

TYPE-C

Dual outputs:

Max 60W 5V/3A, 9V/3A, 12V/3A

15V/3A, 20V/3A

Supports Apple 2.4A,

PPS/PD3.0/PD2.0, QC4+/QC4/

QC3.0/QC2.0, AFC, FCP,

Low-voltage SCP/High-voltage SCP,

PE2.0/PE1.1, SFCP fast charging protocol

Type-C1:PD65W 5V5A 9V5A
12V5A 15V5A 20V5A
Type-C2:5V2.4A

Two outputs:

100W 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A

Supports Apple 2.4A, PPS/PD3.0/PD2.0,

QC4+/QC4/QC3.0/QC2.0, AFC, FCP,

Low-voltage SCP/High-voltage SCP, PE2.0/PE1.1,

SFCP fast charging protocol

DC output

Car charger

12V 10A 120W Max

121W,13.5V DC,9A Max

 13.2V 10A 132W Max

DC5525

/

/

Two 13.2V 5A 132W Max

AC output

Sine wave

Chinese Standard: 220V-240VAC single-phase output
50Hz, rated output power: 600W
US/Japanese Standard: 100V-120VAC single-phase output
Output, 60Hz, rated output power: 600W
EU/AU/UK Standard: 220V-240VAC
Single-phase output, 50Hz
Rated output power: 600W

Chinese Standard:

220V ± 10V, 60Hz/50Hz ± 3Hz

US/Japanese Standard:

110V ± 10V, 60Hz/50Hz ± 3Hz

EU/UK Standard:

230V ± 10V, 60Hz/50Hz ± 3Hz

Chinese Standard: Four 220V-240VAC single-phase outputs, 50Hz

Rated output power: 2200W

US/Japanese Standard: Four 100V-120VAC single-phase outputs,

60Hz, Rated output power: 2200W

EU/AU/UK Standard: Four 220V-240VAC single-phase outputs,

50Hz, Rated output power: 2200W

Wireless charging

/

/

5V/1A, 12V/1.25A support Qi protocol

LED lighting

Three modes: always on, off, and SOS

/

Medium brightness - High brightness - SOS - Strobe - Off (5 modes cycle)

Cycle life

>,1000 times

>,2000 times

>,1000 times

Accessories

AC charging cable/instruction manual

Adapter/Car Charger Adapter/Instruction Manual

AC charging cable/car charging cable

Product size (mm)

251×145×152

290×230×220

 422×288×306

Product weight (kg)

5.1

10.5

15

Charging temperature

0～45℃

0～40℃

0～45℃

Operating temperature

-20～60℃

-10～40℃

-10～45℃

Battery protection

a. Overvoltage protection b. Undervoltage protection c. Discharge overcurrent protection d. Short circuit protection e. Charge overcurrent protection f. Temperature protection
