Wheeled energy storage | |||
| Product Model | W30 Pro | W50 Pro |
Battery | Battery Capacity | 3072Wh | 5120Wh |
Cell Model | 60AH-PL13162255 | 50AH-PL13162225 | |
Battery Charging Temperature | 0-40°C | 0-40°C | |
Battery Discharging Temperature | -10-40C | -10-40C | |
Input | Charging Input Voltage | 29.2V | 58.4V |
Charging Input Current | 20A | 20A | |
Maximum Charging Power | 584W | 1168W | |
Full Time | 5h | 5h | |
Charging Efficiency | >88% | >88% | |
Solar Charging | MPPT,30V-46VDC,500W | MPPT,60V-90VDC,1000W | |
Car charger Output | Output Power | 120W max | 120W max |
Output Voltage/Current | 11.5-13.2V/10A Max | 11.5-13.2V/10A Max | |
USB-A Output | Output Power | Total 36W Max | Total 36W Max |
Output Voltage/Current | 12V/2A | 12V/2A | |
USB-C Output | Output Power | 27W Max | 27W Max |
Output Voltage/Current | 5±0.25V/3A;9±0.45V/3A | 5±0.25V/3A;9±0.45V/3A | |
AC Output | Output Power | 3000W | 5000W |
Output Peak Power | 6000W | 6000W | |
Output Voltage/Frequency | 220V±5%,60Hz/50Hz±3Hz | 220V±5%,60Hz/50Hz±3Hz | |
Conversion Efficiency | >89% | >89% | |
Mechanical Parameters | Dimensions | 575×421×285mm | 660×550×240mm |
Weight | 31.5kg | 49.5kg | |
